Annealer

Application of the machine: 1) This machine is the particular equipment for production of the high tenacity,low elongation polyester staple fiber 2) This machine can also be used to in the finishing section as the third drafterMain specifications: 1) The specification of the roller: 700 x 750/900/1,150 (the length is decidedby production capacity) 2) The surface temperature of the roller: 180 degree centigrade (thetemperature can be adjusted according to the technology) 3) The contact length of the tow with the roller surface is 25.8775m 4) The heating time of the tow is about 7.76 second when the drawing speedis about 200m/min 5) Heating media: cycle heating of high temperature steam (the pressure of thesteam should be 2.5MPa) or media oil 6) This machine is divided into 3 sections, and consists 15 heating rollers; 5rollers per group 7) The drive power for the 3 groups: 200kW for the first group, 110kW for thesecond group, 110kW for the third group 8) The external size of the machine: 8,300 x 3,800 x 2,080mm 9) The weight of the machine: about 21,000kg x 3
